With updraded H.265 encoding technology, Dahua Lite series camera has efficient video encoding capacity, which saves bandwidth and storage space. This camera adopts the latest starlight technology and displays better colorful image in the environment of low illumination. It supports SD card storage, waterproof function, dust-proof function and tamper-proof function, complying to the standards of IP67 and IK10.
Smart ( H.265+ & H.264+ )
Adopting advanced algorithm of auto stream control according to the environment, Dahua smart encoding technology realizes the higher efficiency than (H.265 & H.264 ), providing high-quality video, and reducing the cost of storage and transmission.
Wide dynamic range (WDR)
Dahua adopts advanced Wide Dynamic Range (WDR) technology. You can get clear details in the environment of strong brightness contrast. In high brightness and back-light environment, bright region and dark region with strong light source, you can also get clear images.
Starlight
Dahua Starlight technology mainly applies to the environment of low illumination, and it can provide clear colorful video. Even in the environment of min. illumination, the technology can guarantee the good image effect.
Intelligent Video Analysis (IVS)
With advanced video algorithm, Dahua camera supports intelligent detection, such as tripwire and intrusion and so on.
Cyber Security
Dahua network camera is equipped with a series of key security technologies, such as security authentication and authorization, access control, trusted protection, encrypted transmission, and encrypted storage, which improve its security defense and data protection, and prevent malicious programs from invading the device.
Protection (IP67, IK10, wide voltage)
IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. IK10: The enclosure can stand the punch more than 5 times from a 5 kg hammer falling from a height of 40 cm (Impact energy is 20J). Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.
Features
- 1/3” progressive scan CMOS 4.0 Megapixel
- Resolution - 4mpx (2688 × 1520); 3.7Mpx (2560×1440); 3Mpx (2304×1296); 1080p (1920×1080); 1.3M (1280×960); 720p (1280×720); D1 (704×576/704×480); VGA (640 ×480); CIF (352 × 288/352 × 240).
- Video Frame Rate - Main stream: 2688×1520 (1 fps-20 fps), 2560×1440 (1 fps-25/30 fps) - Sub stream: 704×576 (1 fps-25 fps), 704×480 (1 fps-30 fps).
- Support H.265+ / H.265 / H.264 / H.264+ & MJPEG triple-stream encoding
- IVS analysis - crossing the line (tripwire), intrusion.
- OSD functions: Real WDR 120dB, Day/Night(ICR), ROI, 3D-DNR, AWB, AGC, BLC, HLC, Mirror, Privacy Masking.
- Audio: Built-in Mic - Compression: G.711a/ G.711Mu/ AAC/ G.726.
- Audio Interface I/O: 1/1 audio (RCA) inputs/output;
- Alarme interface I/O: 1/1 alarm inputs/output;
- Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
- 2.8mm fixed lens - Max. IR LEDs Length 30m, Starlight & Smart IR technology.
- Micro SD memory - Micro SD memory cards up to 256GB support (possible local recording)
- Waterproof IP67, Vandalproof IK10, 12V DC/POE (802.3af) power support.
IVS Dahua Technology - More information click here!
Standard:
TCP/IP
Sensor:
1/3" Progressive Scan CMOS
Matrix size:
4.0 Mpx
Scanning system:
Progressive
Resolution:
2688 x 1520 - 4 Mpx , 2560 x 1440 - 3.7 Mpx , 2304 x 1296 - 3 Mpx , 1920 x 1080 - 1080p , 1280 x 960 - 1.3 Mpx 1280 x 720 - 720p
Lens:
fixed-focal 2.8 mm, M12
View angle:
121° x 102° x 55°(diagonal x horizontal x vertical)
Range of IR illumination:
30 m - 8pcs (IR LEDs)0.008Lux/F1.6Smart IR & Starlight technology
RS-485 interface:
No
Memory card slot:
Micro SD memory cards up to 256GB support (possible local recording)
Image compression method:
H.265+ / H.265 / H.264+ / H.264 / MJPEG
Alarm inputs / outputs:
1 / 1
Audio inputs / outputs:
1 / 1 (RCA) - Built-in Mic.
Audio compression
G.711a; G.711Mu; G.726
Bitrate:
32 ... 6144 kbps - H.264 12 ... 6144 kbps - H.265
Main stream frame rate:
4Mpx - 2688 × 1520 (1 fps-20 fps) 3.7Mpx - 2560 × 1440 (1 fps-25/30fps)
Network interface:
10/100 Base-T (RJ-45)
Network protocols:
IPv4/IPv6, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, IEEE 802.1x, Bonjour
WEB Server:
Built-in
Max. number of on-line users:
20
ONVIF:
18.06
Main features:
WDR - 120 dB - Wide Dynamic Range
3D-DNR - Digital Noise Reduction
ROI - improve the quality of selected parts of image
BLC - Back Light Compensation
HLC - High Light Compensation (spot)
ICR - Movable InfraRed filter
AGC - Automatic Gain Control
Mirror - Mirror image
Motion Detection - max. 4 zones
Privacy zones - max. 4
Auto White Balance
IVS analysis : crossing the line (tripwire), intrusion.
Power supply:
PoE (802.3af),
12 V DC / 480 mA
Power consumption:
< 5.4 W
Mobile phones support:
Port no.: 37777 or access by a cloud (P2P)
Android: Free application gDMSS Plus
iOS (iPhone): Free application iDMSS Plus
Default IP address:
192.168.1.108
Default admin user / password:
admin / - The administrator password should be set at the first start
Web browser access ports:
80, 37777
PC client access ports:
37777
Mobile client access ports:
37777
Port ONVIF:
80
Housing:
Dome - Metal
Color:
White
"Index of Protection":
IP67
Vandal-proof:
IK10
Operation temp:
-40 °C ... 60 °C
Weight:
0.38 kg
Dimensions:
Ø 108.9 x 55(H)mm
Supported languages:
Polish, English, Czech, French, Spanish, Dutch, German, Portuguese, Russian, Italian
Manufacturer / Brand:
DAHUA
