Featuring powerful optical zoom and accurate pan/tilt/zoom performance, the camera provides a wide monitoring range and great detail. The camera delivers 1080P resolution at 25/30fps. The camera is equipped with smooth control, high quality image, and good protection, meeting compact size demands of video surveillance applications.
Starlight Technology
For challenging low-light applications, Dahua’s Starlight Ultra-low Light Technology offers best-in-class light sensitivity, capturing color details in low light down to 0.005 lux. The camera uses a set of optical features to balance light throughout the scene, resulting in clear images in dark environments.
Wide Dynamic Range
The camera achieves vivid images, even in the most intense contrast lighting conditions, using industry-leading wide dynamic range (WDR) technology. For applications with both bright and low lighting conditions that change quickly, True WDR (120 dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video.
Smart H.265+
Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces bit rate and storage requirements by up to 70% when compared to standard H.265 video compression.
Environmental
Dahua cameras operate in extreme temperature environments, rated for use in temperatures from -30°C to +60 °C (-22 °F to +140°F) with 95% humidity. Subjected to rigorous dust and water immersion tests and certified to the IP66 Ingress Protection rating makes it suitable for demanding outdoor applications.
Protection
The camera allows for 6KV lightning rating,which provides effective protection for both the camera and its structure against lightning.
Interoperability
The camera conforms to the ONVIF (Open Network Video Interface Forum) specifications, ensuring interoperability between network video products regardless of manufacturer.
Features
- 1/2.8” STARVIS progressive scan CMOS 2.0 Megapixel
- Wi-Fi Module - IEEE802.11a/b/g/n/ac - Dual-Band Wi-Fi, Range: 50 m (open area)
- Support H.265+/H.265/H.264+/H.264/MJPEG decodifica dual codec
- Max 25/30fps@1080P FULL HD (1920×1080)
- 2.7~8.1mm Varifocal motorized lens (3x) - Max. IR LEDs Length 15m, Starlight & Smart IR technology.
- OSD functions: Real WDR 120dB, Day/Night(ICR), ROI, 3D-DNR, Mirror, AWB, AGC, BLC/HLC.
- IVS analysis fuctions - Tripwire, Intrusion, Abandoned/Missing, Face Detection.
- Micro SD memory - Micro SD memory cards up to 256GB support (possible local recording)
- Audio in interface, built-in microphone.
- Waterproof IP66, Vandalproof IK08
IVS Dahua Technology - For More Information "Click Here! "
Standard:
TCP/IP
Sensor:
1/2.8 " STARVIS™ CMOS
Matrix size:
2.1 Mpx
Resolution:
1920 x 1080 - 1080p 1280 x 720 - 720p
Lens:
2.7 ... 8.1 mm
View angle:
105.6 ° ... 35.2 ° (manufacturer data) 100.0 ° ... 46.0 ° (our tests result)
Optical zoom:
x 3
Digital zoom:
No
Range of IR illumination:
15 m
S/N ratio:
> 50 dB (AGC off)
Video output:
No
Rotation speed (manual control):
0.1 °/s ... 70 °/s (horizontal) 0.1 °/s ... 30 °/s (vertical)
Preset rotation speed:
max. 80 °/s (horizontal) max. 40 °/s (vertical)
Horizontal rotation range:
0 ° ... 355 ° - Rotation of the head is limited by stops
Vertical rotation range:
5 ° ... 90 °
RS-485 interface:
No
Number of presets:
300
Horizontal scan:
Yes
Route settings:
8
Image compression method:
H.265+ / H.265 / H.264+ / H.264 / MJPEG
Bitrate:
448 ... 8192 kbps
Alarm inputs / outputs:
No
Main stream frame rate:
25 fps - 1080p
Memory card slot:
Micro SD memory cards up to 256GB support (possible local recording)
Network interface:
10/100 Base-T (RJ-45)
Network protocols:
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPoE, DDNS, FTP, IP Filter, QoS, Bonjour, IEEE 802.1x
WEB Server:
Built-in, NVR compliance
Max. number of on-line users:
20
ONVIF:
16.12
Audio:
Microphone built-in,
External microphone input,
Audio output
Mobile phones support:
Port no.: 37777 or access by a cloud (P2P)
Android: Free application DMSS
iOS (iPhone): Free application DMSS
Default admin user / password:
admin / - The administrator password should be set at the first start
Default IP address:
192.168.1.108
Web browser access ports:
80, 37777
PC client access ports:
37777
Mobile client access ports:
37777
Port ONVIF:
80
Main features:
Wi-Fi module - IEEE 802.11 b/g/n/ac, Antenna - SMA socket
WDR - 120 dB - Wide Dynamic Range
2D-DNR, 3D-DNR - Digital Noise Reduction
ROI - improve the quality of selected parts of image
F-DNR (Defog) - Reduction of image noise caused by precipitation
Motion Detection
ICR - Movable InfraRed filter
BLC/HLC - Back Light / High Light Compensation
Day/night mode
Configurable Privacy Zones
Intelligent 3D Positioning System
IVS analysis : face detection, crossing the line (tripwire), intrusion, abandoned/missing object
Power supply:
12 V DC / 1.5 A
Power consumption:
≤ 10.5 W
Housing:
Speed Dome, Metal + Plastic
Color:
Black + White
"Index of Protection":
IP66
IK rating:
IK08
Operation temp:
-30 °C ... 60 °C
Weight:
0.53 kg
Dimensions:
Ø 128 x 63 mm
Supported languages:
Polish, English, Czech, French, Spanish, Dutch, German, Portuguese, Russian, Italian
Manufacturer / Brand:
DAHUA
