Featuring powerful optical zoom and accurate pan/tilt/zoom performance, the camera provides a wide monitoring range and great detail. The camera delivers 2MP resolution at 25/30fps. The camera is equipped with smooth control, high quality image, and good protection, meeting compact size demands of video surveillance applications.
Wide Dynamic Range
The camera achieves vivid images, even in the most intense contrast lighting conditions, using industry-leading wide dynamic range (WDR) technology. For applications with both bright and low lighting conditions that change quickly, True WDR (120 dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video.
High Efficiency Video Coding (H.265)
The H.265 (ITU-T VCEG) video compression standard offers double the data compression ratio at the same level of video quality, or substantially improved video quality at the same bit rate, as compared to older video compression technologies. H.265 offers such impressive compression by expanding the pattern comparison and difference-coding, improving motion vector prediction and motion region merging, and incorporating an additional filtering step called sample-adaptive offset filtering.
Starlight Technology
For challenging low-light applications, Dahua’s Starlight Ultra-low Light Technology offers best-in-class light sensitivity, capturing color details in low light down to 0.005 lux. The camera uses a set of optical features to balance light throughout the scene, resulting in clear images in dark environments.
Environmental
Dahua cameras operate in extreme temperature environments, rated for use in temperatures from -30 °C to +60 °C (-22 °F to +140 °F) with 95% humidity. The camera complies with the IK10 Vandal Resistance impact rating. Subjected to rigorous dust and water immersion tests and certified to the IP66 Ingress Protection rating makes it suitable for demanding outdoor applications.
Interoperability
The camera conforms to the ONVIF (Open Network Video Interface Forum) specifications, ensuring interoperability between network video products regardless of manufacturer.
Features
- 1/2.8” STARVIS™ CMOS da 2.1 Megapixel
- Wi-Fi Module - IEEE 802.11 b/g/n, Gamma : 50 m (open area)
- Resolution - 1080p (1920×1080); 1.3M (1280×960); 720p (1280×720); D1 (704×576/704×480).
- Video Frame Rate - Main stream: 1080P/720P/D1 (1 ~ 25/30fps) - Sub stream 1: D1/CIF(1 ~ 25/30fps) - Sub stream 2: 720P/D1/CIF (1 ~ 25/30fps)
- Support H.264 / H.265 & MJPEG dual codec
- OSD functions - Real WDR(120dB), Day/Night(ICR), ROI, 2/3D-DNR, Defog, AWB, AGC, BLC/HLC, Digital zoom 16x, Privacy Masking.
- IVS analysis fuctions - Tripwire, Intrusion, Abandoned/Missing, Face Detection.
- Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
- 2.7-11mm Varifocal motorized lens (4x) - Min. illumination: 0.005 Lux (color) / 0.0005 Lux (B/W), Starlight technology.
- Micro SD memory - Micro SD memory cards up to 128GB support (possible local recording)
- Metal structure with Vandalproof IK10 & IP67 Waterproof protection rating.
IVS Dahua Technology - More information click here!
Standard:
TCP/IP
Sensor:
1/2.8 " STARVIS™ CMOS
Matrix size:
2.1 Mpx
Resolution:
1920 x 1080 - 1080p , 1280 x 960 - 1.3 Mpx , 1280 x 720 - 720p
IR illuminator:
No
Lens:
2.7 ... 11 mm
View angle:
113 ° ... 30 ° (manufacturer data)
105 ° ... 35 ° (our tests result)
Optical zoom:
x 4
Digital zoom:
x 16
Min. illumination:
0.005 Lux (color) 0.0005 Lux (B/W)
S/N ratio:
> 50 dB (AGC off)
Preset rotation speed:
100 °/s (horizontal)
60 °/s (vertical)
Rotation speed (manual control):
0.1 °/s ... 100 °/s (horizontal)
0.1 °/s ... 60 °/s (vertical)
Horizontal rotation range:
0 ° ... 355 - Rotation of the head is limited by stops
Vertical rotation range:
0 ° ... 90 °
Protocols:
DH-SD
RS-485 interface:
No
Number of presets:
300
Horizontal scan:
Yes
Route settings:
5
Image compression method:
H.265 / H.264 / MJPEG
Audio:
No
Bitrate:
448 ... 8192 kbps
Alarm inputs / outputs:
No
Main stream frame rate:
25 fps @ 1080p
Network interface:
10/100 Base-TX (RJ-45)
Network protocols:
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPoE, DDNS, FTP, IP Filter, QoS, Bonjour, IEEE 802.1x
Memory card slot:
Micro SD memory cards up to 128GB support (possible local recording)
WEB Server:
Built-in, NVR compliance
Max. number of on-line users:
20
ONVIF:
18.06
Mobile phones support:
Port 37777
Android: Darmowa aplikacja gDMSS Plus
iOS (iPhone): Darmowa aplikacja iDMSS Plus
Main features:
Wi-Fi module - IEEE 802.11 b/g/n, Range : 50 m (open area) ; Antenna - SMA socket
WDR - 120 dB - Wide Dynamic Range
2D-DNR, 3D-DNR - Digital Noise Reduction
F-DNR (Defog) - Reduction of image noise caused by precipitation
ROI - improve the quality of selected parts of image
BLC/HLC - Back Light / High Light Compensation
Configurable Privacy Zones
Motion Detection
Sharpness - sharper image outlines
ICR - Movable InfraRed filter
Mirror - Mirror image
AGC - Automatic Gain Control
Day/night mode
IVS analysis : face detection, crossing the line (tripwire), intrusion, abandoned/missing object
Power supply:
12 V DC / 460 mA
Power consumption:
≤ 5.5 W
Housing:
Speed Dome, Metal
Color:
White
Supported languages:
Polish, English, Czech, French, Spanish, Dutch, German, Portuguese, Russian, Italian
Operation temp:
-30 °C ... 60 °C
"Index of Protection":
IP66
Vandal-proof:
IK10
Weight:
0.61 kg
Dimensions:
Ø 123 x 89 mm
Manufacturer / Brand:
DAHUA
