Box 1 PZ Shipping 24/48H

Dahua XVR5116HS-I3 series AI 1U WizSense penta-brid 2k hd+ 16CH 5M-N 5IN1 HDCVI/AHD/HDTVI/PAL/IP AI-coding p2p smd plus face detection ivs IoT

Name: Dahua XVR5116HS-I3 series AI 1U WizSense penta-brid 2k hd+ 16CH 5M-N 5IN1 HDCVI/AHD/HDTVI/PAL/IP AI-coding p2p smd plus face detection ivs IoT
SKU: XVR5116HS-I3
Price: 171.75 EUR
Availability: InStock

In stock

SKU: XVR5116HS-I3

qty: 9

Description

Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.

Dahua Technology, a world-leading video-centric smart IoT solution and service provider, debuted its new XVR series, XVR5000-I3 Series featuring max.full-channel SMD Plus to benefit customers from AI upgrade (The number of channels differs depending on the model. Please refer to the specifications below for information on the number of channels.). This series has been developed to reduce false-alarm rates and the cost of human surveillance, thus bringing great value to customers in search of products with accurate human/vehicle alarm to raise the security level of various indoor and outdoor facilities.

Face Recognition
Dahua Face Recognition technology extracts the features of captured faces and compares them with that in face database to recognize the person identity. The Face Recognition is conflicted with SMD Plus and Perimeter Protection.

Perimeter Protection
Automatically filters out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to act secondary recognition for the targets. Improves alarm accuracy.

SMD Plus
With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and filter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm

Smart Dual Illuminators
With Smart Dual Illuminators technology, you can select Smart Illumination Mode for the system to automatically switch between IR mode and white light mode. It allows white light to be turned on when a target is detected by the SMD Plus/Perimeter Protection function of AI-enabled XVR. This significantly reduces light pollution at night. Together with other modes, including IR Mode and White Light Mode, the smart dual illumination technology can meet the requirements of a wide variety of scenes.

One-click Arming/Disarming
With just one click, you can enable or disable alarm linkages to show messages, send emails, output audio alarms and more, through the mobile app and platform.

Customizable Alarm Audio
Designed for your convenience, the TiOC alarm can be customized to meet your needs. It is flexible, allowing you to directly upload your customized audio through the mobile app and XVR.

AI Coding
Compared with H.265/H.264, AI coding can reduce more than 50% bit rate and storage requirements without loss of decoding compatibility, providing clear human and vehicle details.

Audio over Coax
The integrated design can reduce wiring troubles which makes it much more cost-effective and convenient for install

IVS Dahua Technology - More information click here!

Data sheet

Standard: AHD, HD-CVI, HD-TVI, CVBS, TCP/IP Video inputs: 16 pcs BNC Video outputs: 1 pcs HDMI 1 pcs VGA Audio inputs: 1 pcs - CINCH 16 - Audio support via coaxial cable, HD-CVI only Audio outputs: 1 pcs CINCH Image compression method: AI Coding / H.265+ / H.265 / H.264+ / H.264 Image records resolutions: AHD / HD-CVI / HD-TVI : 5M-N - 1296 x 1440 , 4M-N - 1280 x 1440 , 1080p - 1920 x 1080 , 1080N - 960 x 1080 , 720p - 1280 x 720 , CVBS : 960H - 960 x 576 IP : max. 6 Mpx - 3072 x 2048 Recording speed adjustment: 6 Mpx IP @ 1 ... 25 fps 5M-N @ 1 ... 10 fps 4M-N @ 1 ... 15 fps 1080p @ 1 ... 15 fps 1080N @ 1 ... 25 fps 720p @ 1 ... 25 fps 960H @ 1 ... 25 fps for each channel Operation modes: 16 x AHD / HD-CVI / HD-TVI / CVBS / IP + 8 x IP Recording modes: Manual, Motion Detection, Schedule Supported hard drives: 1 x 16 TB SATA External storage devices backup: Save single frames and whole records from DVR drive to the USB drive Searching and playback the records: Records searching: by time + timeline with record type. Playback: forward, fast, slow, step Advanced searching (to the one second accuracy) Intelligent face search AI - simultaneous search in the archive of face recordings based on max 8 photos taking into account the similarity threshold (for each photo separately) 1/4/9/16 channel synchronous playback Network functions: Full support via network, Remote records copying, Web Server built-in max. 128 on-line users Mobile phones support: Port no.: 37777 or access by a cloud (P2P) Android: Free application DMSS iOS (iPhone): Free application DMSS Alarm inputs / outputs: No PTZ control: IP Speed Dome Cameras Control compatible with coax PTZ HD-CVI RS-485 - PELCO-D/P Motion Detection: Split the screen into zones : 22 x 18 motion zones Main features: Cooperation with Dahua devices working in the concept of the Internet of Things (IoT), POS - support the machines installed in the points of sales and displaying the date from them as overlaid text on selected channel window, SMD PLUS - searching for an object classified as: human, motor vehicle Coax Audio/Alarm support, Intelligent Image Analysis : crossing the line (tripwire), intrusion, classification of people and vehicles advanced face recognition and search functions Support for up to 10 face databases, including 10 000 face images Detection of faces not included in the device database Searching for faces in recordings based on max 8 selected photos with the ability to independently set the similarity threshold for each photo USB: 1 pcs USB 2.0 1 pcs USB 3.0 Mouse support: Yes IR remote controller in the set: No Power supply: 12 V DC / 2 A (power adapter included) Color: Black Weight: 1.03 kg Dimensions: 260 x 236 x 48 mm Supported languages: Polish, English, Czech, Danish, Finnish, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Hungarian, Italian Country of origin: China Manufacturer / Brand: DAHUA
