MeanWell HDR-60-12 Ultra Slim Power Supply Step Shape DIN Rail Single Output 54W 12V 4.5A

MEANWELL

MeanWell HDR-60-12 Ultra Slim Power Supply Step Shape DIN Rail Single Output 54W 12V 4.5A

Name: MeanWell HDR-60-12 Ultra Slim Power Supply Step Shape DIN Rail Single Output 54W 12V 4.5A
SKU: HDR-60-12
Price: 15.75 EUR
Availability: InStock

In stock

SKU: HDR-60-12

qty: 6

Description

The MeanWell HDR-60-12 is a 60W ultra-slim DIN rail power supply designed to be mounted on TS-35/7.5 or TS-35/15 rails, with a width of only 52.5mm (3SU), optimizing space inside electrical cabinets. It supports an AC input from 85VAC to 264VAC (up to 277VAC operational) and complies with European standards for harmonic currents (BS EN/EN61000-3-2). Its plastic housing provides effective protection against electrical hazards. With an efficiency of up to 87%, the HDR-60 operates in an ambient temperature range of -30℃ to 70℃, thanks to natural air convection. Additionally, it offers complete protection against short circuits, overvoltage, and overloads, and is certified for use in home automation and industrial control (IEC62368-1, UL508, UL62368-1, BS EN/EN61558-2-16), making it an ideal solution for both residential and industrial applications.

Data sheet

Type:	DIN rail
No of Outputs	Single Output
Output Power:	54W
Output voltage:	12V
Input Voltage	120V to 370V
Output current:	4.5A
Input voltage (VAC):	85VAC to 264VAC
Ripple and noise:	120mVp-p
Load regulation (%):	1%
Operating temperature range:	-30°C to +70°C
Switching Frequency-Max:	63Hz
Insulation:	Isolated
Mounting method:	DIN rail mounting
Dimensions	52.5x90x54.5mm (WHD)
Weight	190g

More Information

SKU Padre	HDR-60-12
Ean	4711287421728
Shipping	Shipping 24/48H
Warranty	2 years warranty
Packaging	1
Dimensions	52.5x90x54.5mm
Voltage	12V
Waterproof	No waterproof
Watts	54
Operating temperature	-20°C to 55°C
